个人工具站Personal Tools

把测试台上重复的活，做成工具Turning repetitive bench work into tools

高速串行链路与光模块测试相关。COM 算链路余量，REA 出眼图，CMIS 管光模块寄存器。开源的直接下载，商业的提供免费试用 —— 试用 key 在右下角对话框里报个 Host ID，当场就发。High-speed serial link and optical module test. COM computes link margin, REA produces eye diagrams, CMIS manages optical module registers. Open-source tools download directly; commercial ones come with a free trial — send your Host ID in the chat box at the bottom right and the key comes back on the spot.

工具清单All tools

5 items
v3.0.0
MIT 开源 · 免费MIT open source · free
26.3 MB
2026-10-05 10:22
下载 0 次0 downloads

Codex/CC Auto-Continue

Codex 与 Claude 的 Windows 自动续接工具A Windows auto-continue companion for Codex and Claude

Codex EXE、Codex CLI 和 Claude CLI 通过三个切换栏使用各自设置，活动日志固定在底部。Codex 桌面最近活动默认显示 5 个，可自定义；每个会话可独立设置模型、推理强度和完成后续接。支持额度恢复与有限网络重试，权限默认完全访问，自动工具权限批准默认开启，也可改为等待人工批准。最近活动支持配置；自动输入只作用于核实的当前可见 Codex 会话，不监测 ChatGPT 普通聊天或 Work 会话。单文件免安装。Codex desktop, Codex CLI and Claude CLI have separate settings in three tabs, with the activity log at the bottom. Desktop recent activities default to five and are configurable, with per-session model, effort and follow-ups. Supports quota recovery and bounded network retries. Full access and automatic tool approval are defaults; manual approval is available. Recent activities can be configured; automatic input requires a verified visible Codex conversation. ChatGPT chats and Work conversations are excluded. Single file, no install.

  • Codex EXECodex desktop
  • Codex CLI
  • Claude CLI
  • MIT 开源MIT licensed
  • 免安装No install
v3.0.0 更新What's new in v3.0.0　2026-10-05
  • 改进ImprovedCodex EXE、Codex CLI 和 Claude CLI 使用三个切换栏，设置按类型显示，活动日志固定在底部。Codex desktop, Codex CLI and Claude CLI use three tabs with settings for the selected type and the activity log at the bottom.
  • 新增NewCodex 桌面最近活动默认显示 5 个，可自定义数量；每个活动均可单独设置模型、推理强度和完成后续接，同名会话分别保存。Desktop recent activities default to five and are configurable. Each activity has separate model, effort and follow-up settings, including conversations with identical titles.
  • 新增NewCodex Advanced 增加权限模式与自动工具权限批准开关；默认完全访问且自动批准开启，可切换为等待人工批准。普通选择菜单、模型对话框和登录提示由用户处理。Codex Advanced adds permission modes and an automatic tool-approval switch. Full access and automatic approval are defaults; waiting for manual approval is available. General pickers, model dialogs and login prompts remain manual.
  • 修复Fixed轮询刷新不再打断模型下拉选择或未完成的自定义输入；未打开的最近活动也能保存配置。Polling no longer interrupts model dropdowns or unfinished custom input. Recent activities can save their configuration before being opened.
  • 改进ImprovedGitHub 仓库更名为 Codex/CC Auto-Continue，程序更新与源码链接同步使用新地址。The GitHub repository is renamed Codex/CC Auto-Continue, with updater and source links aligned to the new address.
以往版本更新Earlier releases 4
v2.3.2　2026-10-03
  • 修复Fixed修复 Codex 桌面 App 在限额期间只填入 continue、发送恢复可用后仍未提交的问题。Retains the pending Codex desktop follow-up while Send is unavailable and submits it when native Send becomes usable.
  • 修复Fixed消息确认提交后才计入重试或跟进次数；修改草稿、切换聊天、跳过或排除窗口会取消待发送。Counts retries and follow-ups only after submission is confirmed. Editing the draft, switching chats, Skip or Exclude cancels the pending send.
v2.3.1　2026-10-03
  • 修复Fixed修复真实 Codex 桌面任务已有中间回复或工具记录后，再出现限额提示时漏识别的问题。Recognises native quota errors after commentary or tool output in actual Codex desktop tasks.
  • 修复FixedApp 内部重试时明确显示限额状态，待 App 可输入后才继续；历史错误和引用文本不会触发恢复。Shows quota state during the App's internal retries, holding input until ready. Historical errors and quoted text do not trigger recovery.
v2.3.0　2026-10-02
  • 修复Fixed修复 Codex CLI 被误识别为 Claude，以及切换终端标签页后残留 Claude 标记的问题。Fixes Codex CLI being misidentified as Claude and stale Claude labels after terminal tab switches.
  • 修复Fixed发布包仅保留一个 Auto-Continue.exe，修复打包环境导致程序无法启动的问题。Ships one Auto-Continue.exe and fixes startup failures caused by the build environment.
  • 新增New新增 Codex 桌面 App 自动继续，可与 CLI 分别或同时监控，支持错误恢复和任务完成后续接。Adds Codex desktop App auto-continue, independently or alongside the CLI, with recovery and follow-ups.
  • 改进ImprovedCLI 与桌面 App 各有独立参数、模型与强度、续发次数和排除设置；草稿、菜单和会话切换暂停发送。CLI and App have separate timing, model/effort, loop counts and exclusions. Drafts, menus and conversation switches hold sends.
v2.2.0　2026-10-02
  • 新增New新增 Codex CLI 自动继续，支持单独 Claude、单独 Codex 或同时监控，设置与状态相互独立。Adds Codex CLI auto-continue, with Claude-only, Codex-only or combined monitoring and independent settings and state.
  • 新增NewCodex 支持额度重置恢复、有限次数网络重试和任务完成后续接，模型与推理强度可逐窗口设置，只应用于当前会话。Codex supports usage-reset recovery, bounded network retries and follow-ups, with per-window model and reasoning effort applied only to the current session.
  • 改进Improved基于真实 Codex CLI 窗口适配；草稿、运行中任务和确认菜单暂停自动输入。Claude 原监控逻辑保持不变。Adapted against real Codex CLI windows. Drafts, active turns and confirmation dialogs hold automatic input. Existing Claude monitoring remains unchanged.
AI 助手技能 · Claude Code / CodexAI Skills · Claude Code / Codex让 AI 助手自己去读 Auto-Continue 的日志Lets your AI assistant read Auto-Continue's log

Claude Code 和 Codex 都可以安装此可选技能，读取活动日志并排查配置。v3.0.0 主程序支持 Codex EXE、Codex CLI 和 Claude CLI 的独立监测；运行主程序不依赖技能。Both Claude Code and Codex can use this optional skill to read logs and diagnose settings. The v3.0.0 executable independently watches Codex desktop, Codex CLI and Claude CLI. The executable does not require the skill.

Claude Code　%USERPROFILE%/.claude/skills/auto-continue/
Codex　%USERPROFILE%/.agents/skills/auto-continue/

解压后，将里面的技能文件夹放到对应目录；无需两份都安装。Extract the archive and copy its skill folder to the directory for your assistant.

v3.0.0　·　8.4 KB　·　MIT 开源 · 免费MIT licensed · free下载技能包Download skill ↓
技术规格Specifications 6
目标场景Target setup
Codex 桌面版 / Codex CLI / Claude CLICodex desktop / Codex CLI / Claude CLI
最近活动Recent activities
Codex 桌面默认 5 个，可自定义；自动输入需当前可见会话Five by default, configurable; automatic input requires a visible conversation
Codex 设置Codex settings
逐会话模型、推理强度与续接；CLI 和 EXE 各自独立权限设置Per-session model, effort and follow-ups; separate CLI and desktop permission settings
自升级Self-update
GitHub 与下载站双渠道，支持断点续传GitHub and download-site sources, resumable downloads
系统Platform
Windows 10 / 11
协议License
MIT 开源，完全免费MIT, completely free
历史版本Earlier versions 4
下载Download 源码 ↗Source ↗
v0.1.1
MIT 开源 · 免费MIT · free
45.8 MB
2026-09-28 08:23
下载 2 次2 downloads

AI Passport 虚拟机AI Passport VM

在电脑上跑 AI Passport 手表的真固件，Windows 双击即用Run real AI Passport watch firmware on your PC — one Windows exe

把 AI Passport 手表（ESP32-C3）整机模拟在浏览器里：屏幕、按键、音频、虚拟 Wi-Fi 都能用，打包成一个 exe，不用装 Node.js。默认开机跑 Claude Control 演示——手表里模拟一台开着几个 Claude Code 窗口的电脑，不联网就能把会话、选项框（审批、提问、计划确认）、上下文翻看、提醒、语音的流程看一遍；也能换 FoloToy 官方 Demo 等内置固件、上传自己的固件，或粘贴 FoloToy 社区玩法链接。模拟器基于 VOID001/FoloToy-Passport-Simulator。Emulates the whole AI Passport watch (ESP32-C3) in the browser — screen, buttons, audio and a virtual Wi-Fi — packaged as a single exe, no Node.js needed. Boots the Claude Control demo by default: a scripted computer with several Claude Code windows inside the watch, so the sessions, choosers (approvals, questions, plan approval), conversation history, alerts and voice flow can be seen without any network. Other built-in firmware (such as the FoloToy official demo), your own image, or a FoloToy community link can be loaded too. Based on VOID001/FoloToy-Passport-Simulator.

  • AI Passport
  • 手表模拟器Watch emulator
  • Windows
  • 单文件Single exe
v0.1.1 更新What's new in v0.1.1　2026-09-28
  • 新增New选择页：Claude Code 里要你选一项的框都能在手表上答（权限提示、多道题的提问含多选和语音输入、计划确认），选项和电脑屏幕上一致。Chooser page: answer Claude Code's choosers on the watch — permission prompts, multi-question prompts with multi-select and voice input, plan approval — with the same options shown on the computer.
  • 新增New上下文页：点进一个会话即可一页一页往前翻看最近的对话。Context page: open a session to browse its recent conversation page by page.
  • 改进Improved演示固件会轮流演示三种选项框，每个会话都有一段对话可以翻看。The demo firmware plays all three chooser kinds and has a conversation to browse in every session.
  • 修复Fixed外网试用用完时被拒的录音，手表上显示说明，不再是原始代码。When a voice request is refused because the remote trial is used up, the watch now explains why instead of showing a raw code.
以往版本更新Earlier releases 1
v0.1.0　2026-09-27
  • 新增New首个版本：Windows 单文件 exe，双击即用；默认运行 Claude Control 演示固件，可切换 FoloToy 官方固件、上传本地固件或导入社区玩法；关掉窗口即退出。First release: a single Windows exe, double-click to run; boots the Claude Control demo firmware, can switch to the FoloToy firmware, upload a local image or import a community play; closing the window quits.
AI 助手技能 · Claude Code / CodexAI Skills · Claude Code / Codex让 AI 助手读启动日志、解释固件和配对操作Read launcher logs and get help with firmware and pairing

Claude Code 和 Codex 都可以用这个技能排查虚拟机打不开、白屏或按键没反应，了解怎么加载固件、使用 Claude Control 演示和配对连接电脑。读取日志后再判断，不凭印象猜；装不装都不影响虚拟机本身运行。Claude Code and Codex can both use this skill to diagnose launch failures, blank screens, or unresponsive buttons, and help with firmware loading, the Claude Control demo, and pairing. It reads launcher logs before drawing conclusions. The simulator runs fine without it.

Claude Code　%USERPROFILE%/.claude/skills/ai-passport-vm/
Codex　%USERPROFILE%/.agents/skills/ai-passport-vm/

解压后，将里面的技能文件夹放到对应目录；无需两份都安装。Extract the archive and copy its skill folder to the directory for your assistant.

v0.1.1　·　6.7 KB　·　MIT 开源 · 免费（技能包）MIT licensed · free (skill package)下载技能包Download skill ↓
技术规格Specifications 4
平台Platform
Windows 10 / 11，Chrome 或 EdgeWindows 10 / 11, Chrome or Edge
内置固件Built-in firmware
Claude Control 演示（默认）、Claude Control 连接电脑、FoloToy 官方固件 4 个Claude Control demo (default), Claude Control connect, 4 FoloToy firmware images
模拟范围Emulated
屏幕、按键、音频、虚拟 Wi-Fi；不支持 BLE / NFC / 电量计Screen, buttons, audio, virtual Wi-Fi; no BLE / NFC / battery gauge
Claude Control 固件Claude Control firmware
专有软件（闭源），只以二进制随本模拟器提供Proprietary (closed source), shipped as binaries with this simulator only
历史版本Earlier versions 1
下载Download 源码 ↗Source ↗
v2.0.30
商业授权 · 免费试用Commercial · free trial
↘ 右下角对话框报 Host ID，免费领试用 key↘ Send your Host ID in the chat box (bottom right) for a free trial key
235.0 MB
2026-10-10 21:22
下载 0 次0 downloads

REARapid Eye Analysis

S 参数进，眼图和余量出S-parameters in, eye diagram and margin out

从 S 参数直接算眼图：FFE / DFE / CTLE 联合优化，支持独立的浮动 FFE/DFE 抽头搜索。电眼之外也做光眼、TDECQ 与 EECQ，并给出 FEC 纠错前后的误码率。Normal 与 Expert 共用均衡优化流程，可以通过 SCPI 接进自动化测试。Computes eye diagrams straight from S-parameters: joint FFE / DFE / CTLE optimization with independent floating FFE/DFE tap search. Handles optical eyes, TDECQ and EECQ as well as electrical eyes, and reports pre- and post-FEC BER. Normal and Expert share equalization optimization and can be driven over SCPI.

  • S 参数眼图S-parameter eye
  • FFE / DFE / CTLE
  • FEC 前后 BERPre/post-FEC BER
  • TDECQ
  • SCPI 远程SCPI remote
  • EECQ
  • IBIS-AMI
v2.0.30 更新What's new in v2.0.30　2026-10-10
  • 修复Fixed修复部分低通传输脉冲在起始时刻出现异常尖峰的问题；边沿平滑后的脉冲首点也保持正确。Fix an artificial initial spike in some lowpass transmission impulse responses, including responses with edge smoothing.
  • 改进Improved补充中英文 TDR/TDT 使用说明：区分阶跃、脉冲及参考幅度，核对时统一输入频点、端口和显示条件。Clarify bilingual TDR/TDT guidance: distinguish step, impulse and reference amplitude, and match input grids, ports and display conditions for comparisons.
以往版本更新Earlier releases 5
v2.0.29　2026-10-10
  • 修复Fixed修复级联、去嵌和分割窗口中，部分曲线组的“全选／全不选”按钮点击后报错的问题；选择操作只影响对应曲线组。Fix errors when clicking Select all / Deselect all for trace groups in Cascade, Deembed and Splitter; each action affects its own group.
  • 修复Fixed通过 SCPI 分割时，未加载文件或分段比例之和无效会立即返回错误，避免弹窗阻塞远程操作；GUI 保留输入提示。Return SCPI errors immediately for a missing splitter input or invalid ratio sum, avoiding modal blocking; retain GUI validation prompts.
  • 修复Fixed修复 S 参数窗口切换语言后，窗口标题、已绘制曲线标题和图例未同步更新的问题；保留曲线选择与缩放范围。Update S-parameter window titles, cached plot labels and trace groups when switching language; preserve selected traces and zoom.
  • 修复Fixed修复格式转换切换语言时重置输出类型和端口顺序、导致已有预览异常的问题。Preserve the selected conversion output and port order when switching language, preventing errors in existing previews.
  • 改进Improved补充分割比例的完整列表示例，并同步中英文说明和 REA-Skill；不新增 SCPI 命令。Clarify the complete splitter ratio list in bilingual documentation and REA-Skill; no SCPI commands are added.
v2.0.28　2026-10-08
  • 改进Improved改善多组 Floating FFE 的选位，按整套位置与系数比较候选；收益以重新生成的眼图为准。Improve multi-group Floating FFE placement by comparing complete tap layouts and coefficients; confirm gains with a regenerated eye.
  • 修复Fixed修复部分噪声预算和浮动抽头约束在 GUI、SCPI 与 Normal 到 Expert 复制时不一致的问题。Align noise budgets and floating-tap constraints across the GUI, SCPI and Normal-to-Expert copying.
  • 修复Fixed保存与加载配置时保留浮动 FFE／DFE 的系数、位置及判决时间，避免旧布局残留；修复加载后通道路径显示和复制不一致。Preserve floating FFE/DFE coefficients, positions and decision timing in saved configurations, clear stale layouts, and align loaded channel paths for display and copying.
  • 新增New随包增加 Floating FFE 专题的 S 参数、可复现配置、参考图片与文件说明。Bundle Floating FFE S-parameter examples, reproducible configurations, reference images and a file guide.
  • 修复Fixed载入配置按新通道应用数据率上限，避免沿用旧通道上限而静默截断速率。Apply the incoming channel rate limit when loading configurations, avoiding silent clipping by the previous channel limit.
v2.0.27　2026-10-08
  • 改进Improved浴盆曲线按 Eye 编号上下分行，每眼分别显示相位和电压曲线，缺失眼保留位置及提示。Separate bathtub curves into rows by eye number, with phase and voltage panels for each eye and placeholders for missing eyes.
  • 修复FixedExpert 浴盆视图通过探针下拉或结果表切换，一次显示一个探针并保留其全部子眼。Switch Expert bathtub probes with the picker or result table; show one probe at a time with all its eyes visible.
  • 修复Fixed修正浴盆图中文缺字显示，标题、说明和图例在探针切换、语言切换及详情窗口中保持清晰。Correct missing Chinese glyphs in bathtub titles, notes and legends across probe switches, language changes and detail windows.
  • 改进Improved浴盆坐标轴按有效数据自适应，区分实测与外推曲线，Home 恢复自适应范围。Adapt bathtub axes to valid data, distinguish measured and extrapolated curves, and restore adaptive limits with Home.
  • 改进ImprovedExpert 图表设置收纳到二级窗口，简化主工具栏；外观、标注与判决设置关闭后保留。Move Expert plot controls into a secondary window and simplify the main toolbar; retain appearance, annotation and decision settings after closing.
  • 改进Improved拖动浴盆 BER 线可连续联动所有眼，即时显示该 BER 下的眼高和眼宽，松开后刷新自适应范围。Drag the BER line to adjust all eyes continuously and read their EH/EW at the shared target; release restores adaptive bounds.
  • 修复Fixed修复 BER 目标修改后浴盆图未即时刷新的问题，Normal、Expert 和已打开详情同步更新。Refresh bathtub plots immediately after a target BER change, synchronizing Normal, Expert and open detail views.
  • 修复Fixed修复部分 GUI 参数编辑后 SCPI 查询滞后，保持浮动均衡、电平、RX 上升时间与 CDR 覆盖开关同步，并改善频偏查询精度和 DFE 抽头数读回。Synchronize GUI edits of floating equalizers, levels, RX rise time and CDR overrides with SCPI queries; improve frequency-offset precision and DFE tap-count readback.
  • 改进Improved修复封装窗口 PCB 标题、启用框和光学示意图文字与连线重叠，补齐封装、测量条件及 DFE 步进的查询同步。Fix overlapping PCB title controls and optical schematic labels; synchronize package, measurement-condition and DFE-step edits with queries.
  • 改进Improved统一参数输入框的紧凑列宽和对齐，覆盖信号端口、TX/RX FFE、DFE、封装和 CDR 网格；长预设在下拉中完整查看，避免撑宽窗口。Use consistent compact input widths and alignment in signal ports, TX/RX FFE, DFE, package and CDR grids; show full preset names in the popup without widening the window.
  • 修复Fixed补齐已打开参数及反馈、更新、Marker、坐标轴、AMI、串扰、COM 导入和关于窗口的中英文切换，保留草稿和任务进度；模型示意图按语言缓存，Signal、Filter 按钮保留英文名称。 已加载文件信息、曲线分组、耗时和 Smith 工具栏同步切换语言，保留原数据与时间值。Translate open parameter, feedback, update, Marker, axis, AMI, crosstalk, COM-import and About windows while retaining drafts and task progress; cache diagrams by language and retain English Signal and Filter button names. Translate loaded file summaries, trace groups, timings and Smith toolbar controls while retaining data and recorded times.
  • 修复Fixed动态重建后的 TX FFE、RX FFE 和 DFE 抽头编辑即时同步到已有 SCPI 查询，旁路状态也能读回；窄浴盆说明自动换行。Synchronize rebuilt TX FFE, RX FFE and DFE tap edits with existing SCPI queries even for bypassed stages; wrap captions in narrow bathtub views.
  • 改进Improved同步更新中英文手册、快速入门和 REA SCPI 技能说明，保持已有命令与计算结果。Update bilingual manuals, Quick Start guides and the REA SCPI skill while preserving existing commands and calculation results.
  • 修复Fixed补齐子图布局、图形参数、坐标轴选择和数值导出窗口的中英文翻译，语言切换保留编辑草稿及图形数据。Translate plot-layout, figure-options, axis-selection and value-export dialogs while preserving drafts and plot data across language changes.
v2.0.26　2026-10-05
  • 改进Improved优化大规模 CPU/GPU 眼图指标计算，在已验证场景中保留原有测量结果。Improve large CPU/GPU eye-metric calculations while preserving measurement results in the validated scenarios.
  • 修复Fixed修正光电模型的频率相位和有限带宽处理；指定频响文件不可用时明确报错并停止计算。Correct frequency phase and finite-bandwidth handling in optical models. An unusable specified response file reports an error and stops the calculation.
  • 修复Fixed浴盆图缺少子眼数据时保留有效曲线，明确显示数据不足和总体开口不可用；越界眼号返回空响应，并修复 Expert 浴盆详情的双击打开。Keep usable bathtub curves while clearly reporting missing eye data and unavailable overall opening. Out-of-range eye queries return an empty response; double-click access to Expert bathtub details is fixed.
  • 修复Fixed修复快速清空、切换文件时旧结果回填或待加载文件停滞的问题。Prevent stale results or stalled queued loads when files are rapidly cleared or switched.
  • 修复Fixed完善 DFE 边界检查和零抽头处理，并修复可选 GPU 安装助手的错误反馈及运行库加载。Improve DFE boundary checks and zero-tap handling, and fix optional GPU setup error reporting and runtime loading.
  • 修复Fixed修复反馈记录首次被多个进程同时打开时的加锁失败，保留并发写入的记录。Fix first-use feedback history locking when multiple processes open the same file, preserving concurrent entries.
  • 改进Improved同步更新中英文手册、快速入门和 REA SCPI 技能说明。Update the bilingual manuals, Quick Start guides and companion REA SCPI skill.
v2.0.25　2026-10-04
  • 修复Fixed插值、级联、去嵌和文件导出保留逐频、逐端口参考阻抗，修复结果参考标注错误。Preserve frequency-dependent and per-port reference impedances during interpolation, cascade, de-embedding and Touchstone export.
  • 修复Fixed眼图模板任意命中都判为失败；缺少子眼数据时明确显示数据不足，避免误判通过。Any eye-mask hit fails the measurement. Missing eye data is reported explicitly and cannot produce an overall pass.
  • 修复Fixed反馈历史并发保存不再互相覆盖；保存失败会保留待存回复、提示用户并自动重试。Keep concurrent feedback-history updates. Storage errors retain pending replies, show a message and retry automatically.
  • 改进Improved同步更新中英文手册和授权提示，按完整 Key 激活；明确 MLSE 实测尚未在正式版本开放。Update bilingual manuals and activation guidance to use the complete supplied key, and clarify that measured MLSE is not yet released.
AI Skills · Claude Code / Codex

配套技能说明如何通过 SCPI 驱动 REA、读回结果并核对界面；已与 v2.0.30 同步，新增 TDT 首样本、边沿平滑与 GUI/TCP 对照要求，保留曲线组和分割验证；保留既有眼图与均衡案例说明。安装技能不影响 REA 的商业授权要求。This skill explains SCPI control and GUI verification for REA v2.0.30, adding TDT initial-sample, edge-smoothing and GUI/TCP checks while retaining trace-group and splitter verification, while retaining existing eye and equalization guidance. Installing the skill does not change REA licensing requirements.

Claude Code　%USERPROFILE%/.claude/skills/rea-scpi/
Codex　%USERPROFILE%/.agents/skills/rea-scpi/

解压后，将里面的技能文件夹放到对应目录；无需两份都安装。Extract the archive and copy its skill folder to the directory for your assistant.

v2.0.30　·　108.6 KB下载技能包Download skill ↓
SHA-256 5512a63694c401aaac14aee265e640566bba3ec597f1d047c2bed0d266de0f72
技术规格Specifications 8
授权License
商业授权；提供免费试用，试用 key 在页面右下角的咨询窗口报 Host ID 即时领取Commercial; free trial available, send your Host ID in the chat box at the bottom right to get a trial key instantly
均衡优化Equalization
FFE / DFE / CTLE · Normal / Expert 共用优化流程 · 独立浮动 FFE/DFE 抽头搜索 · FFE+DFE 联合求解 · CPU/GPU 结果复核 · 802.3 族预设携带抽头限值 · 优化摘要与事件提示FFE / DFE / CTLE · shared Normal / Expert optimization · independent floating FFE/DFE tap search · joint FFE+DFE solution · CPU/GPU result checks · 802.3 family presets with tap limits · optimization summary and events
光眼Optical
光眼图 · TDECQ · EECQ · 802.3dj D3.1 参考均衡器主方法 (15 FFE + 1 DFE, Table 180-16 限值)Optical eye · TDECQ · EECQ · 802.3dj D3.1 reference-equalizer primary method (15 FFE + 1 DFE, Table 180-16 limits)
码型Patterns
PRBS7–31 · PRBSnQ（Gray 四进制）· SSPR / SSPRQ · 自定义PRBS7-31 · PRBSnQ (Gray quaternary) · SSPR / SSPRQ · custom
FEC
纠错前后误码率 · 802.3dj D3.1 / 802.3ck / 802.3bs Cl 119 / Cl 91 KR4 / Cl 74 BASE-R · PCIe 6/7/8 FLIT · 802.3dj IM-DD 光口 Inner FEC（TDECQ 均衡眼口径）BER before and after correction · 802.3dj D3.1 / 802.3ck / 802.3bs Cl 119 / Cl 91 KR4 / Cl 74 BASE-R · PCIe 6/7/8 FLIT · 802.3dj IM-DD optical Inner FEC (TDECQ reference-equalized eye)
远程控制Remote control
SCPI over TCP/IP
输出Output
眼高 / 眼宽 / 余量Eye height / eye width / margin
器件模型Device models
IBIS 8.0 / IBIS-AMI (专家模式节点)IBIS 8.0 / IBIS-AMI (Expert-mode node)
历史版本Earlier versions 5
SHA-256 cec878a69763fee15193d99dd5ac2f92e6b905da4fb871f79e2898e5fe573458
下载Download GitHub ↗
v1.7.8
商业授权 · 免费试用Commercial · free trial
↘ 右下角对话框报 Host ID，免费领试用 key↘ Send your Host ID in the chat box (bottom right) for a free trial key
245.9 MB
2026-08-20 00:01
下载 11 次11 downloads

COM ToolCOM Calculator

算 802.3 链路余量，不用装 MATLAB 完整版IEEE 802.3 link margin, without a full MATLAB license

把 IEEE 802.3 官方 COM 脚本包成了带界面的工具。丢进 .s4p 通道文件，选好标准和数据率，出 COM / ERL 数值和 PDF 报告。109 个 IEEE 参数可以在界面里直接改，多个 case 并行跑。装 MATLAB Runtime 就行，不需要 MATLAB 完整版。Wraps the official IEEE 802.3 COM MATLAB script in a desktop GUI. Drop in a .s4p channel file, pick the standard and data rate, and get COM / ERL figures plus a PDF report. All 109 IEEE parameters are editable in the interface and multiple cases run in parallel. Needs only MATLAB Runtime — a full MATLAB license is not required.

  • IEEE 802.3
  • COM / ERL
  • SCPI 远程SCPI remote
  • VNA 联机VNA integration
v1.7.8 更新What's new in v1.7.8　2026-08-20
  • 修复Fixed在线更新途中关掉「检查更新」窗口不再让界面卡住数秒，之后退出软件也不会闪退。网络不通或被代理拦住时最容易碰到。Closing the update window while a check is still running no longer freezes the interface for several seconds, and the app no longer crashes when you later exit. This was easiest to hit on networks that are blocked or behind a proxy.
  • 修复Fixed软件在后台向作者查询反馈回复期间退出，不会再闪退。Exiting the app while it is checking in the background for replies to your feedback no longer crashes.
  • 新增New升级会自动把您改过的配置文件、算出来的结果，以及自己放进来的 S 参数文件带到新版本里。同名文件以您的为准；旧版本目录仍会原样改名保留，随时可以取回。Upgrading now carries your edited configuration files, computed results and any S-parameter files you added into the new version. Your file wins on a name clash, and the previous installation is still kept alongside under a renamed folder so nothing is lost.
  • 修复Fixed升级或更换硬件后，剩余试用次数不再被误判为已用完。已经激活的授权也不会因此失效。Remaining trial runs are no longer mistaken for exhausted after an upgrade or a hardware change, and an already-activated license no longer stops working because of it.
  • 新增New试用次数用完时，提示窗里可以一键申请：自动带上机器码、版本和授权状态发给作者，不用再手抄机器码。若软件发现您的次数可能被早前的版本误判，也会主动提示并引导申请。When the trial allowance runs out, the dialog offers a one-click request that sends your machine code, version and license status to the author automatically — no more copying the machine code by hand. If the app detects that an earlier version may have miscounted your runs, it says so and offers the same request.
  • 改进Improved安装新版本时若还有计算在跑，会提示先等它结束，不再半路中断计算；解包阶段显示文件进度并可随时取消。Installing an update while a computation is still running now asks you to let it finish instead of cutting it off midway, and the extraction step shows file-by-file progress and can be cancelled.
  • 改进Improved更新全过程会写一份日志，升级出问题时可以据此定位。The whole update process now writes a log, so an upgrade problem can be traced afterwards.
以往版本更新Earlier releases 4
v1.7.7　2026-08-14
  • 修复Fixed反馈里的截图过大时改为整体等比缩小，不再裁掉边角——要报的错常常正好在被裁掉的那个角上。An oversized screenshot in a feedback report is now scaled down as a whole instead of cropped — the error being reported is often in exactly the corner that used to get cut off.
  • 修复Fixed反馈发送受限时的提示分清了两种情况：过一会儿能恢复的，和本次会话额度已用完、再等也没用的。When feedback sending is rate-limited, the message now distinguishes a limit that clears on its own from a per-session quota that no amount of waiting will restore.
  • 新增New快速入门新增「意见反馈」章节（中英文各一节）：怎么描述问题、Ctrl+V 贴图、选填邮箱、未读回复在哪看。The quick-start guide gains a Feedback chapter in both Chinese and English: how to describe an issue, paste a screenshot with Ctrl+V, leave an optional email, and where unread replies show up.
v1.7.6　2026-08-14
  • 修复Fixed反馈回复区分「机器人」和「作者本人」两种署名，不会再把自动回复当成作者亲自回的。Replies to your feedback now show whether they came from the bot or from the author, instead of attributing every reply to the author.
v1.7.5　2026-08-14
  • 新增New作者对反馈的回复可以直接在软件里看到，取回后本地留存，不会因为读过一次就消失。Replies from the author now appear inside the app and are kept locally, so a reply is not lost once it has been fetched.
v1.7.4　2026-08-14
  • 新增New帮助 → 意见反馈：写文字、Ctrl+V 贴截图（最多 3 张）或拖放、选文件，直接发给作者，与下载站右下角的咨询走同一条通道、同一个会话。邮箱／微信号选填。自动附带软件版本、操作系统、Host ID 与授权状态，窗口里原样显示要发的内容并可取消勾选——不做隐藏上报。Help → Send Feedback: type your message and attach up to three screenshots by Ctrl+V, drag-and-drop or file picker, sent straight to the author through the same channel and session as the chat box on the download site. Email or WeChat ID is optional. Version, OS, Host ID and license status are attached — shown in the dialog exactly as they will be sent, and you can untick them. Nothing is reported silently.
  • 新增NewSCPI 同步支持发送反馈与查询通道在线状态（SYST:FEED / SYST:FEED:CONT / SYST:FEED:ONL?）。后端离线是常态而非故障，脚本可以先探再发。SCPI can send feedback and query channel availability (SYST:FEED / SYST:FEED:CONT / SYST:FEED:ONL?). The backend being offline is normal rather than a fault, so a script can probe before sending.
技术规格Specifications 11
授权License
商业授权；提供免费试用，试用 key 在页面右下角的咨询窗口报 Host ID 即时领取Commercial; free trial available, send your Host ID in the chat box at the bottom right to get a trial key instantly
计算引擎Compute engine
com_ieee8023_4p14p0.m v4.14.0 (MATLAB)
标准支持Standards
Annex 93A / 162A / 178A · 802.3ck · 802.3dj 草案Annex 93A / 162A / 178A · 802.3ck · 802.3dj draft
数据率Data rates
25G / 50G / 100G / 200G per lane（含 1.6T = 8 × 200G）25G / 50G / 100G / 200G per lane (incl. 1.6T = 8 × 200G)
输入格式Input format
Touchstone .s4p · 端口序 [1,3,2,4]Touchstone .s4p · port order [1,3,2,4]
VNA 集成VNA support
Keysight PNA / PNA-X / ENA · R&S ZNB / ZNA · Anritsu ShockLine / VectorStar
远程控制Remote control
SCPI over TCP/IP :5026 · 247 条命令SCPI over TCP/IP :5026 · 247 commands
并行Parallelism
1–16 个 case 同时跑1–16 cases at once
报告输出Report output
PDF · CSV · 信道 PNG · JSON 配置PDF · CSV · channel PNG · JSON config
测试覆盖Test coverage
619 项单元测试619 unit tests
系统Platform
Windows 10 / 11 (x64) · 简体中文 / EnglishWindows 10 / 11 (x64) · Simplified Chinese / English
历史版本Earlier versions 4
下载Download GitHub ↗
v2.213.0
MIT 开源 · 免费MIT open source · free
9.9 MB
2026-10-05 14:04
下载 0 次0 downloads

CMIS Module Manager

光模块寄存器，不用再啃 200 页规范Optical module registers, without re-reading 200 pages of spec

按 OIF CMIS 5.4 与 SFF-8024 解析模块管理寄存器，提供 CH341 / CH347 / CP2112 / MCP2221 与两种 FTDI USB-I2C 后端。12 种 Mock 用于无硬件管理演示，支持 Bank/Page、应用配置、告警、监控、诊断与调谐。dj 参数依据为 D3.1 草案；合成诊断不执行 FEC 解码，也不作 IEEE PHY 合规判定。LR1 光功率监督采用 ETCC ≤ 1 dB 条件。解压双击使用，MIT 开源、免费、可商用。CMIS 5.4 and SFF-8024 module management through CH341, CH347 or FTDI USB-I2C adapters. Twelve mocks cover bank/page, application, alarm, monitor, diagnostic and tuning workflows. IEEE P802.3dj references use draft D3.1; synthetic diagnostic fixtures do not implement FEC decoding or establish PHY compliance. LR1 power supervision assumes ETCC <= 1 dB. MIT licensed, free for commercial use.

  • OIF CMIS 5.4
  • 1.6T / 800G
  • MIT 开源MIT licensed
  • 解压即用No install
v2.213.0 更新What's new in v2.213.0　2026-10-05
  • 修复Fixed功率阈值未读回或读取失败时，保留读数而不判告警；应用切换后失败的阈值读取会在后续刷新重试。Unavailable optical power thresholds no longer trigger alarm colouring. Failed threshold reads after an Application change are retried on later monitoring refreshes.
  • 改进ImprovedSNR 跳过保留区和未支持的测量侧，双侧数据读取减少一半，并保留逐读数一致性。SNR skips reserved data and unsupported measurement sides, halving dual-side data reads while preserving scalar coherency.
  • 修复Fixed原始读取 Network Path 与 VDM 锁存标志后，保存已读事件的 Bank、地址、位和时间，后续读取失败也不会丢失。Raw Network Path and VDM flag reads retain acquired events with their bank, address, bits and timestamps, including when a later read fails.
以往版本更新Earlier releases 4
v2.212.0　2026-10-05
  • 改进Improved维护发布：重新构建 Windows 客户版，同步操作手册版本与更新日期，修正六种硬件后端的说明并补充审查回归测试命令。Maintenance release: rebuild the Windows customer executable, synchronize the operator manual version and date, clarify the six hardware backends and document the audit regression command.
v2.211.0　2026-10-01
  • 修复Fixed配置未明确成功时保持整个 Data Path 的 DP Deinit，防止超时后在旧配置上启动。Keep the complete Data Path deinitialized unless ConfigSuccess is confirmed.
  • 修复Fixed每次成功读取 COR 告警立即保全，后续 Mask、状态或分块读失败不再丢失历史。Retain COR events immediately, including when later auxiliary or chunk reads fail.
  • 修复Fixed按 Bank/Page 组合验证映射；空读和短读立即报错；能力发现失败或未来 CMIS 主版本拒绝连接。Verify each Bank/Page mapping, reject short transfers, failed discovery and future CMIS major versions.
  • 修复Fixed普通与裸写软件复位共用 MgmtInit 重试窗口，复位及自主重启清缓存并重新发现能力；Windows 重试使用高精度时钟。Share reset hold-off and rediscovery across control/raw writes and autonomous restarts; use a precise Windows retry clock.
  • 修复Fixed裸写 CDB 按广告检查触发格式；测试失败返回非零退出码。Honor advertised CDB trigger formats and return a nonzero exit code for failing tests.
  • 修复Fixed修正 ZR 应用为 800ZR-A/B；补齐固定和可调波长广告、修正 SR8 范围；16 lane 档位说明为两个独立 800G 应用。Correct ZR Applications to 800ZR-A/B, wavelength advertisements and SR8 range; identify the sixteen-lane fixture as two 800G Applications.
  • 修复FixedMock 比特计数随应用、方向和 Checker 位置变化；完整门控按绝对截止点累计，结果不受刷新频率影响。Select synthetic bitstream rates by Application, direction and Checker position; count complete absolute gate intervals independent of polling.
  • 改进Improved区分 FEC 编码器/解码器提示及合成测量面，显示 ResetErrorInformation 冻结；同步 12 种 Mock 和 dj D3.1 草案范围。Explain encoder/decoder positions, synthetic measurement planes and reset freezing; document twelve mocks and the dj D3.1 scope.
  • 修复Fixed数值输入严格解析，拒绝被截断、含尾随字符或超出范围的值。Parse numeric inputs strictly and reject truncated, trailing-character and out-of-range values.
v2.176.0　2026-09-27
  • 修复FixedSignal Integrity 表:只声明前游标均衡控制的模块,Rx EQ Pre 一列改为读规范规定的后游标字节,不再读模块会忽略的前游标字节;同时声明前、后游标的模块不受影响。Signal Integrity table: on modules that advertise pre-cursor equalization control only, the Rx EQ Pre column now reads the post-cursor bytes, as the specification requires, instead of the pre-cursor bytes the module ignores. Modules that advertise both are unaffected.
v2.175.0　2026-09-27
  • 修复FixedMonitoring 页 Tx Bias 列的标题按模块的偏置倍率写出每个计数的大小:倍率为 2 或 4 的模块上,一个计数是 4 µA 或 8 µA,不再一律写成 2 µA;读数本身不变。The Tx Bias column header on the Monitoring tab now states the size of one count for the module’s bias multiplier: 4 µA or 8 µA on ×2 or ×4 modules, rather than 2 µA everywhere. The readings themselves are unchanged.
AI 助手技能 · Claude Code / CodexAI Skills · Claude Code / Codex让 AI 助手直接问模块，而不是凭印象讲 CMISLets your AI assistant read the actual module

装进 Claude Code 或 Codex 的技能目录后，可以直接问「我点了 Apply 为什么没生效」「这个标志位显示 n/a 是什么意思」——工具开着的时候它会通过本机接口去读真实模块再回答。也讲清楚界面上几处最容易误读的地方：闩锁标志读一次就清、暂存配置与生效配置不一致、模块没声明的控制会置灰、偏置电流有刻度倍数。这些都是 CMIS 本身的设计，不看清就会得出相反的结论。Drop it into the skills folder for Claude Code or Codex and you can ask why an Apply did not take effect, or what a flag showing n/a means — with the tool running it reads the actual module through the local API instead of reciting the standard. It also explains the parts of the interface that are easiest to misread: flags that clear when read, a staged configuration the module refused, controls greyed out because the module never advertised them, and the scaling factor on the bias reading.

Claude Code　%USERPROFILE%/.claude/skills/cmis-module-manager/
Codex　%USERPROFILE%/.agents/skills/cmis-module-manager/

解压后，将里面的技能文件夹放到对应目录；无需两份都安装。Extract the archive and copy its skill folder to the directory for your assistant.

v2.213.0　·　34.5 KB　·　MIT 开源 · 免费MIT licensed · free下载技能包Download skill ↓
技术规格Specifications 8
规范Specification
OIF CMIS 5.4 + SFF-8024 Rev 4.14 + IEEE P802.3dj/D3.1
适配器Adapters
CH341 / CH347 / CP2112 / MCP2221 / FTDI (D2XX / pyftdi) USB-I2C
模块Modules
1.6T / QSFP-DD 800G / 400G 等 CMIS 兼容模块，最多 256 通道1.6T / QSFP-DD 800G / 400G and other CMIS-compliant modules, up to 256 lanes
无硬件开发Hardware-free dev
12 种管理 Mock；dj 参考限定 D3.1；16×100G / 2×800G 多 Bank 演示12 management mocks; dj references limited to D3.1; 16×100G / 2×800G multi-bank demo
实时监控Live monitoring
温度、电压、逐通道 Tx/Rx 功率与偏置（按模块实际通道数展开）Temperature, voltage, per-lane Tx/Rx power and bias, sized to the module
技术栈Stack
Flask + 原生 JS，无构建链Flask + vanilla JS, no build chain
测试覆盖Test coverage
3008 项3008 tests
协议License
MIT 开源，可商用MIT, free for commercial use
历史版本Earlier versions 4
下载Download 源码 ↗Source ↗

zhh198903

高速串行 / 光模块测试工具High-speed serial / optical module test tools

做高速串行链路和光模块测试。这几个工具都是自用后整理出来的——先是自己每天要干的活太重复，写了脚本，再慢慢补上界面、测试和文档，最后变成能直接发给同事的 EXE。I work on high-speed serial link and optical module testing. Every one of these tools started as something I built for myself — the daily bench work was too repetitive, so I wrote a script, then gradually added a GUI, tests and docs, until it became an EXE I could hand straight to a colleague.

共同的取向是：解压双击就能跑，不要求你装 Python、配环境或买 MATLAB 完整版；能接进自动化测试流程（多数带 SCPI 远程控制）；手上没硬件也能先跑起来看看（内置 Mock）。CMIS 和 Auto-Continue 已在 GitHub 开源，MIT 协议，可商用；COM 和 REA 是商业工具，提供免费试用，试用 key 在页面右下角的咨询窗口报 Host ID 即时领取。They share the same priorities: unzip and double-click to run — no Python install, no environment setup, no full MATLAB license; they drop into automated test flows (most support SCPI remote control); and you can try them with no hardware on hand (built-in mocks). CMIS and Auto-Continue are open source on GitHub under MIT and free for commercial use. COM and REA are commercial tools offering a free trial — send your Host ID in the chat box at the bottom right to get a trial key instantly.

GitHub ↗
WeChat QR code
高速通信杂谈 · High-Speed Comms Notes
扫码关注，新版本发布、bug 修复第一时间推送Scan to follow — new releases and fixes are announced here first
